10 Star Home Adelaide 2021

10 Star Home Adelaide

As a winner of the Carbon Neutral Adelaide ‘Leadership and Influence’ award in 2020, The 10 Star Home Adelaide will once again be open to educate the public on achieving high performance housing.

Last year the home was under construction and therefore there was a heavy focus on the control layers in construction walls/roof and this year it is complete so you can experience the full integration of services, home automation, energy analysis via technology in the home and how it is aimed to feedback real-time data through the 10starhome website as we watch this sentient home adjust to the environmental conditions.

This house achieved a NatHERS rating of 10 stars using NatHERS accredited software.

Find out how the star ratings work on the Nationwide House Energy Rating Scheme (NatHERS) website.

Sustainability Features

Years Open
2020
2021
ENERGY AND WATER EFFICIENT FEATURES
    • Energy efficiency:
    • Draught proofing
      Efficient lighting
      Efficient appliances
      Energy monitoring
      Smart home features
    • Passive heating cooling:
    • Cross ventilation
      Deciduous planting around house
      External planting
      Heat recovery ventilation system
      Passive solar designed home
      Shading
      Thermal mass
    • Active heating cooling:
    • Ceiling fans
      Heat exchange ventilation system
      Heat pump
    • Water heating:
    • Hot water heat pump
    • Water harvesting and saving features:
    • Rainwater storage - Above ground
    • Average water consumption per day:
    • TBA
    • Above ground rainwater storage Type:
    • 3000L
    • Above ground rainwater storage Size
    • Provision for under deck in future
    • Energy Efficient Lighting
    • LED lights throughout
      Natural daylight
    • Window Protection:
    • Adjustable Shading
      Automation/controls
      Awnings (external)
      Blinds
      Deciduous tree/vegetation
      Drapes/curtains
      Eaves
      External window hoods/surrounds
SUSTAINABLE & RECYCLED MATERIALS
    • Sustainable materials:
    • KESAB Clean Site - 90% of materials taken from site recycled + training provided to industry through the construction by KESAB. Low or neutral VOC materials Reduced construction processes where possible (tapware and some plumbing fixtures) Natural timber oil used - timber as carbon sink Home Automation and data rich display for realtime monitoring of house sentient operation - Lighting and occupant profile and power standby, Battery storage + capacity, PV performance, ERV efficiency and operation, external Helioscreen blind automation and timing for peak periods, Temperature sensor and weatherstation data etc Please visit http://www.10starhome.com.au for more information
    • Recycled and reused materials:
    • Bricks
      Concrete
INSULATION SPECIFICATIONS
    • Insulation Type:
    • Under-roof
      Ceiling
      Internal walls
      External walls
    • Ceiling Type:
    • KNAUF BLOWIN INSULATION, ANTICON BLANKET
    • Ceiling Rating:
    • AS ABOVE
    • Under Roof Insulation Type:
    • Bulk – polystyrene board
    • Under Roof Insulation Rating:
    • 10.6
    • Internal Walls Insulation Type:
    • Knauf Earth Wool
    • Internal Walls Insulation Rating:
    • R2.0
    • External Walls Rating:
    • R4.5
    • External Walls Type:
    • K12 + Earth wool
RENEWABLE ENERGY SPECIFICATIONS
    • All-Electric Home?
    • Yes
    • Energy star rating:
    • 10
    • Renewable energy used:
    • Solar PV grid connect
    • Size of PV system:
    • 5kW
    • Average Daily Energy Consumption:
    • Approx 0.88kWh daily (3MJ/M2 annual) Based on NatHERS 4 person occupancy
COSTS AND COST SAVINGS
    • Total cost of home when constructed:
    • 2020 Completed. Final Construction Cost pending.
    • Cost estimate of sustainable home/features:
    • 100,000
    • Estimate of annual savings:
    • $10,000*
HOUSE DESIGN SPECIFICATIONS
    • House Size
    • 119m2
    • BAL Rating
    • BAL – Low: There is insufficient risk to warrant specific construction requirements
    • Roof
    • Metal (Colorbond)
    • Wall Materials
    • Lightweight construction (timber frame)
      Metal (Colorbond)
      Reverse Brick veneer
      Timber
    • Window and Door Types
    • Awning
      Tilt and turn
      Triple glazing
    • Universal design accessability
    • Adaptive design
      Multi-generational
    • Universal Design Features
    • 80cm minimum door opening width
      Hobless showers
      Loud doorbell/connected to flashing light
      No stairs/steps
      Remote power open and close doors
      Slip resistant flooring
      Window openings easily accessible
    • Number of bedrooms
    • 3
    • Number of bathrooms
    • 2
GARDEN AND WASTE REDUCTION
    • Garden / Outdoors
    • Edible garden
      Native plants
    • Waste Reduction Practices:
    • Recycle
HEALTHY HOME FEATURES
    • Healthy home features
    • Airtight house design
      Automated ventilation system
      Cross flow ventilation
      Heat recovery ventilation (HRV)
      Indoor plants for air filtration
      Low VOC paints/sealer/varnish
      Natural light and ventilation
      Natural oil sealer/finishes
      VOC free paints/sealer/varnish
Location
Woodforde SA 5072
    • Housing Type:
    • Standalone House
    • Project Type:
    • Prototype Home
    • Builder
    • Woolcock Constructions
    • Designer
    • SUHO
