Cairns Avenue 2019

Address
Warradale SA 5046
HOUSE DETAILS
    • Housing Type:
    • Standalone House
    • Open House Style
    • Open House – No booking required
    • Open Hours
    • 10am-2pm
    • Builder
    • Mirage Homes
    • Designer
    • Mirage Homes

Cairns Avenue is an all-electric, 7.5 star sustainable home designed specifically to fit on a narrow (9.9m) wide allotment in a typical suburb. The home is passively designed and utilises a generous setback to the north coupled with extensive uPVC double glazed windows and external shade structures to create year round comfort.

A combination of lightweight external cladding (Shadowclad) plus reverse brick veneer and polished concrete floors gives a good amount of thermal mass and high efficiency electric appliances help dramatically reduce running costs when compared to an average home. The house also has an air tightness level of 4.75 ACH50 (independently tested) and inlcludes LED downlights, ceiling fans & low/zero VOC finishes throughout.

The design team and builder will be present on the day to answer queries and share knowledge.

Designed and built by Mirage Homes



This house achieved a NatHERS rating of 7.5 stars using NatHERS accredited software (FirstRate5). Find out how the star ratings work on the Nationwide House Energy Rating Scheme (NatHERS) website.

SUSTAINABLE FEATURES

Years Open
2019
SUSTAINABLE FEATURES
    • Energy efficiency:
    • Draught proofing
      Efficient lighting
      Efficient appliances
    • Passive heating cooling:
    • Cross ventilation
      Passive solar designed home
      Shading
      Thermal mass
    • Active heating cooling:
    • Ceiling fans
      Heat pump
    • Recycled and reused materials:
    • Bricks
      Rocks/stone
    • Water heating:
    • Hot water heat pump
    • Water harvesting and saving features:
    • Above ground rainwater storage
    • Above ground rainwater storage Type:
    • Corrugated Rainwater Tank
    • Storage connected to
    • Garden
      Toilet
      Laundry
    • Energy Efficient Lighting
    • LED lights throughout
      Natural daylight
    • Electric Vehicle?
    • No
    • Electric Vehicles Welcome
    • No
    • Garden / Outdoors
    • Native plants
      Water wise plants
    • Healthy home features
    • Airtight house design
      Chemical free cleaning products used
      Cross flow ventilation
      Low VOC paints/sealer/varnish
      Natural fibre furnishings
      Natural light and ventilation
      Natural oil sealer/finishes
      No carpets
COSTS AND COST SAVINGS
    • Total cost of home when constructed:
    • $430,000
    • Cost estimate of sustainable home/features:
    • $15,000
    • Estimate of annual savings:
    • $4000 on average over 5 years (independently estimated, based on a family of four)
ENERGY SPECIFICATIONS
    • All-Electric Home?
    • Yes
    • Energy star rating:
    • 7.5 Stars
    • Renewable energy used:
    • Solar PV grid connect
    • Size of PV system:
    • 6kW
INSULATION SPECIFICATIONS
    • Insulation Type:
    • Under-roof
      Ceiling
      Internal walls
      External walls
    • Ceiling Type:
    • Bulk – glass wool
    • Ceiling Rating:
    • R6.0
    • Window Protection:
    • Honeycomb blinds
      Solar pergola
    • Under Roof Insulation Type:
    • Foil Faced Blanket
    • Under Roof Insulation Rating:
    • R1.3
    • Internal Walls Insulation Type:
    • Bulk – glass wool
    • Internal Walls Insulation Rating:
    • R2.0
    • External Walls Rating:
    • R2.5 (batts) + R0.11 (aircell) + R0.65 (reflective cavity) = R3.26
    • External Walls Type:
    • Bulk (glass wool batts) plus Kingspan Air Cell and cavity battens.
HOUSE DESIGN
    • BAL Rating
    • N/A
    • House Size
    • 200m2
    • Number of bedrooms
    • 3
    • Number of bathrooms
    • 2
    • Roof
    • Metal (Colorbond)
    • Wall Materials
    • Lightweight construction (timber frame)
      Reverse Brick veneer
    • Window and Door Types
    • Awning
      Double glazing
      Sliding windows/doors
    • Universal Design Features
    • Hobless showers
      Lever handles for doors (no knobs)
      Minimum 110cm wide hallways
      No stairs/steps
