GOODHOUSE05 2016

House Notes – GOODHOUSE05

This GOODHOUSE was designed to be a low energy, low maintenance, bright, warm and functional home for a young growing family. The house and carport position required careful consideration so as to maximise the entry aesthetic, solar orientation and useful outdoor space.

The building envelope is highly insulated and can be sealed very tightly during the extremes of weather. This, coupled with a carefully integrated approach to both active and passive heating and cooling means the home maintains thermal comfort for very little energy input.

In winter a 1Kw heat pump drives the in-slab hydronic heating as well as supplying domestic HW. The winter sun pours into the living areas further loading the insulated internal thermal mass. This heat is kept inside by the well-sealed and highly insulated building envelope, keeping the internal spaces warm and ready for the next daily cycle.

In summer, window shading, natural ventilation, ceiling fans and the inherently cool thermal mass work together to moderate the internal temperature. During heat waves, the house can be ‘locked down’, keeping the heat out and allowing the internal thermal mass to soak up the internal heat. The windows allow for effective cross and stack ventilation during the cooler nights, allowing the thermal mass to purge the heat collected during the day.

The house is maintaining this level of comfort for under 30% of the average electrical energy use in the local area. It is worth noting that this is without a gas or wood fire.

Sustainability Features

Years Open
2015
2016
ENERGY AND WATER EFFICIENT FEATURES
    • Energy efficiency:
    • Efficient lighting
      Draught proofing
      Efficient appliances
    • Passive heating cooling:
    • Shading
      Cross ventilation
      Thermal chimney
    • Active heating cooling:
    • Hydronic
      Heat pump
      Ceiling fans
    • Water heating:
    • Integrated HW and hydronic in slab heating
    • Water harvesting and saving features:
    • Above ground storage
      Low flow shower heads
      Low flow taps
      Drip irrigation
    • Above ground rainwater storage Type:
    • 2 x tanks
    • Above ground rainwater storage Size
    • 65KL
SUSTAINABLE & RECYCLED MATERIALS
    • Sustainable materials:
    • SIPS, rammed earth
INSULATION SPECIFICATIONS
    • Insulation Type:
    • Ceiling
      Internal and external walls
      Floor
    • Ceiling Rating:
    • R6 batts
    • Floor Type:
    • Waffle pod slab
    • Internal / External Walls Rating:
    • R4+ SIPS, R2.5 batts internal
RENEWABLE ENERGY SPECIFICATIONS
    • Energy star rating:
    • 7.2
    • Renewable energy used:
    • Solar PV grid connect
COSTS AND COST SAVINGS
    • Cost estimate of sustainable home/features:
    • Goodhouse avg. $1900/m2
    • Estimate of annual savings:
    • Goodhouse avg. running costs 1/4 of local avg.
HOUSE DESIGN SPECIFICATIONS
    • House Size
    • 190
    • Window and Door Types
    • Double glazing
      Clerestory windows
    • Number of bedrooms
    • 4
    • Number of bathrooms
    • 2
GARDEN AND WASTE REDUCTION
    • Garden / Outdoors
    • Drip irrigation
      Water wise plants
      Edible garden
      Native plants
HEALTHY HOME FEATURES
    • Healthy home features
    • Low VOC paints, natural fibre carpets
Location
Littlehampton SA 5250
    • Housing Type:
    • Standalone House
    • Project Type:
    • New Build
    • Builder
    • Sierp Homes
