Millennium Wave 2018

House Notes – Millennium Wave

Strine’s classic and unbeatably energy efficient Millennium portfolio concept has been adapted as a split level design, with integrated garage, carport, north pergola and south verandah. The sculptural curved “wave” roof forms add visual impact and dynamic street appeal. This is a functional, minimalist, modern design with two separate bedroom areas zoned either side of the open plan Living/Dining/ Kitchen. The light-filled central hub of the house integrates seamlessly with the outdoor areas to the North and South through large sliding glass doors. The highly insulated building envelope and concrete internal thermal mass ensure that this house needs no cooling in summer and almost no heating in winter.

Sustainability Features

Years Open
2018
ENERGY AND WATER EFFICIENT FEATURES
    • Energy efficiency:
    • Draught proofing
      Efficient lighting
      Energy monitoring
    • Passive heating cooling:
    • Cross ventilation
      Passive solar designed home
      Shading
      Thermal chimney
      Thermal mass
    • Active heating cooling:
    • Ceiling fans
    • Water heating:
    • Water heated by PV system

    • Water heating:
    • Electric heat pump
    • Water harvesting and saving features:
    • Above ground rainwater storage
      Low flow shower heads
      Drip irrigation
    • Above ground rainwater storage Type:
    • Corrugated steel water tank
    • Above ground rainwater storage Size
    • 5,000L
    • Energy Efficient Lighting
    • LED lights throughout
      Natural daylight
    • Window Protection:
    • Adustable Shading
      Deciduous tree/vegetation
      Solar pergola
SUSTAINABLE & RECYCLED MATERIALS
    • Sustainable materials:
    • Precast concrete and mass effect internal walls
INSULATION SPECIFICATIONS
    • Insulation Type:
    • Under roof
      Ceiling
      External Walls
      Floor
    • Ceiling Type:
    • Bulk - glass wool
    • Ceiling Rating:
    • R4.5
    • Floor Type:
    • Vertical concrete slab edge and horizontal perimeter expanded polystyrene
    • Floor Rating:
    • R2.0
    • Under Roof Insulation Type:
    • Anticon foil with fibreglass blanket
    • Under Roof Insulation Rating:
    • R1.5
    • External Walls Rating:
    • R3.9 mass adjusted
    • External Walls Type:
    • Precast concrete sandwich panel insulated with expanded polystyrene
RENEWABLE ENERGY SPECIFICATIONS
    • All-Electric Home?
    • No
    • Energy star rating:
    • 8.0 Stars
    • Renewable energy used:
    • Solar PV grid connect
    • Size of PV system:
    • 6kW
COSTS AND COST SAVINGS
    • Total cost of home when constructed:
    • $600,000
    • Estimate of annual savings:
    • $4,000 to $5,000
HOUSE DESIGN SPECIFICATIONS
    • House Size
    • House 142m2 Garage 25m2 Carport 19m2
    • BAL Rating
    • BAL – Low: There is insufficient risk to warrant specific construction requirements.
    • Roof
    • Metal (Colorbond)

    • Roof
    • Insulated
    • Wall Materials
    • Insulated panels or blocks

    • Wall Materials
    • Precast concrete sandwich panels
    • Window and Door Types
    • Awning
      Clerestory windows
      Double glazing
      Sliding windows/doors

    • Window and Door Types
    • PVC window and sliding door frames
    • Universal design accessability
    • Disability access
    • Universal Design Features
    • 80cm minimum door opening width
      Flush thresholds (no lip) to all external doors
      Hobless showers
      Lever handles for doors (no knobs)
      Loud doorbell/connected to flashing light
      Minimum 110cm wide hallways
      Shower head on rail for various heights
      Window openings easily accessible
    • Number of bedrooms
    • 3
    • Number of bathrooms
    • 2
GARDEN AND WASTE REDUCTION
    • Garden / Outdoors
    • Drip irrigation
      Native plants
      Water wise plants
HEALTHY HOME FEATURES
    • Healthy home features
    • Airtight house design
      Cross flow ventilation
      Natural light and ventilation
      No carpets
Location
Cook ACT 2614
    • Housing Type:
    • Standalone House
    • Project Type:
    • New Build
    • Builder
    • Strine Homes Pty Ltd
    • Designer
    • Strine Design Pty Ltd
