Prefabricated Folding House Bundanoon 2019

Prefabricated Folding House Bundanoon

Prefabricated Folding House Bundanoon is the latest example of a prefabricated construction system developed by Architect Matthew Dynon and MODE homes. Sustainable House Day has featured the smaller Folding

Pavilion in Belmore over the last few years. This year Matthew and MODE homes are showing the latest iteration of the design idea.

A four bedroom, two bathroom home. The home was constructed in the factory, folded down for cost-effective delivery and then folded-out on-site.

The modules arrive on site with all services in place ready for site connection. They then expand on fold-out to almost three times their transportation size. Less time on-site means a substantial reduction in building costs. It also means less disruption and inconvenience to the customer, and an altogether smaller, tighter and more controlled project. Factory-based quality control provides for a level of accuracy and confidence impossible to achieve on-site.

The home has an 8 Star energy-efficiency rating due mainly to the double glazing, high levels of insulation and orientation. MODE homes worked with UNSW to produce a series of reports and modellings to get its homes to 8 Stars in seven out of Australia’s eight climatic zones.

The architect has developed this flexible and adaptive approach to prefabricated housing provision to achieve maximum flexibility and connectivity between modules. The roof design and parapet walls allow modules to connect, slide, rotate, step, extend and stack. The system allows multiple modules to be added in a multitude of ways, to form a vast variety of house plans responding more successfully to the practical requirements of the site and the functional requirements of the consumer. Homes can therefore achieve more appropriate solutions for a wider range of situations.

Barriers exist to housing provision in rural, regional and remote areas of Australia. The biggest of these barriers is geographical distance and the lack of skilled labour. The ‘fold-pack’ system overcomes the tyranny of distance and does not rely on the availability of a local supply of skilled labour. When in transport mode, modules fit within standard load restrictions and are, therefore, cost-effective to deliver.
