Rodway Passive House 2024

House Notes – Rodway Passive House

After helping numerous clients with their dream passive house projects, the owner of this house, a long time Canberran passive house consultant and now window importer, Harley Truong, wanted to move his family together with his parents and in-laws in one big house. This was his third time building a passive house, so rather than being a pioneering effort, this project aimed to use familiar materials and methods, like 90mm timber stud walls and brick, to meet the passive house standard in the tough Canberra climate. The house will be under construction so participants can see the construction method before it is covered up.

See Change an SHD Community Partner is hosting special visits to this site. Visit the link below to obtain tickets.

IMPORTANT: The house is under construction so no children or pets allowed. There will be scaffolding steps to get to the upper storey.

Rodway Passive House Tickets


Sustainability Features

Years Open
2024
ENERGY AND WATER EFFICIENT FEATURES
    • Energy efficiency:
    • Draught proofing
      Efficient lighting
      Efficient appliances
    • Passive heating cooling:
    • Cross ventilation
      Heat recovery ventilation system
      Passive solar designed home
    • Active heating cooling:
    • Heat exchange ventilation system
      Split system airconditioner
    • Water heating:
    • Hot water heat pump
    • Water harvesting and saving features:
    • Rainwater storage - Above ground
    • Above ground rainwater storage Type:
    • tanks
    • Above ground rainwater storage Size
    • 15000L
    • Energy Efficient Lighting
    • LED lights throughout
    • Electric Vehicle Type
    • Tesla
    • Window Protection:
    • Adjustable Shading
      External window hoods/surrounds
SUSTAINABLE & RECYCLED MATERIALS
    • Sustainable materials:
    • Timber flooring and ceiling linings from reclaimed timber. Biax waffle slab - no foam Lower carbon concrete with flyash Aluminium clad timber windows Wood fibre insulation
    • Recycled and reused materials:
    • Timber
INSULATION SPECIFICATIONS
    • Insulation Type:
    • Under-roof
      Ceiling
      Internal walls
      External walls
      Floor
    • Ceiling Type:
    • Blow in high density glass wool
    • Ceiling Rating:
    • R7.0
    • Floor Type:
    • XPS insulation above slab
    • Floor Rating:
    • R3.0
    • Under Roof Insulation Type:
    • none
    • Under Roof Insulation Rating:
    • R0
    • Internal Walls Insulation Type:
    • Wood fibre batts
    • Internal Walls Insulation Rating:
    • R2.3
    • External Walls Rating:
    • R5.0
    • External Walls Type:
    • Wood fibre batts and wood fibre boards
RENEWABLE ENERGY SPECIFICATIONS
    • All-Electric Home?
    • Yes
    • Renewable energy used:
    • Solar PV grid connect
    • Size of PV system:
    • 10kW
HOUSE DESIGN SPECIFICATIONS
    • House Size
    • 340m2
    • BAL Rating
    • BAL – Low: There is insufficient risk to warrant specific construction requirements
    • Roof
    • Metal (Colorbond)
    • Wall Materials
    • Brick veneer
      Lightweight construction (timber frame)
    • Window and Door Types
    • Triple glazing
    • Universal design accessability
    • Adaptive design
      Multi-generational
      Universal access
      Wheelchair accessible
    • Universal Design Features
    • Flush thresholds (no lip) to all external doors
    • Number of bedrooms
    • 5
    • Number of bathrooms
    • 4
HEALTHY HOME FEATURES
    • Healthy home features
    • Airtight house design
      Heat recovery ventilation (HRV)
Location
Yarralumla ACT 2600
    • Housing Type:
    • Standalone House
    • Project Type:
    • New Build
    • Builder
    • Craft Building
    • Designer
    • Envelope Architecture
