Sustainably Designed Townhouses 2020

This profile is written and maintained by the homeowner, architect, or builder. You can ask them questions about their home in the comments below.

Location
Kew VIC 3101
    • Housing Type:
    • High Density Housing/Strata Development/Unit
    • Project Type:
    • New Build
    • Designer
    • Green Design Solutions

About Sustainably Designed Townhouses

The client brief was to develop two solar passive designed homes that would be suitable for multi generational living, where the living area can flow out onto a north facing deck and garden. Design features that contribute to solar passive design include exposed concrete slab with north facing windows, high insulation in walls and ceiling, high performing windows, cross flow ventilation, ceiling fans in all rooms and shading for summer. Additional features in each property include 5kW of panels on north facing roof and 5,000 litre rainwater tank underground in the driveway for both properties.

This house achieved a NatHERS rating of 7.1 stars using NatHERS accredited software.

Find out how the star ratings work on the Nationwide House Energy Rating Scheme (NatHERS) website.

View Featured Video

SUSTAINABLE FEATURES

Years Open
2020
ENERGY AND WATER EFFICIENT FEATURES
    • Energy efficiency:
    • Draught proofing
      Efficient lighting
      Efficient appliances
    • Passive heating cooling:
    • Cross ventilation
      External planting
      Heat recovery ventilation system
      Passive solar designed home
      Thermal mass
    • Active heating cooling:
    • Ceiling fans
      Heat exchange ventilation system
    • Water heating:
    • Hot water heat pump
    • Water harvesting and saving features:
    • Rainwater storage - Underground
      Low flow shower heads
      Low flow taps
    • Average water consumption per day:
    • 95 litres
    • Underground rainwater storage type:
    • concrete
    • Underground rainwater storage Size:
    • 5,000 litres
    • Energy Efficient Lighting
    • LED lights throughout
      Natural daylight
    • Window Protection:
    • Blinds
      Eaves
SUSTAINABLE & RECYCLED MATERIALS
    • Sustainable materials:
    • Exposed concrete slab in living areas facing north
    • Recycled and reused materials:
    • Bricks
INSULATION SPECIFICATIONS
    • Insulation Type:
    • Under-roof
      Ceiling
      External walls
    • Ceiling Type:
    • Rockwool
    • Ceiling Rating:
    • R6.0
    • Under Roof Insulation Type:
    • Reflective foil
    • Under Roof Insulation Rating:
    • R1.0
    • External Walls Rating:
    • R2.5
    • External Walls Type:
    • rockwool
RENEWABLE ENERGY SPECIFICATIONS
    • All-Electric Home?
    • Yes
    • Renewable energy used:
    • Solar PV grid connect
    • Size of PV system:
    • 5kW
    • Average Daily Energy Consumption:
    • 3kW
COSTS AND COST SAVINGS
    • Total cost of home when constructed:
    • 600,000
    • Cost estimate of sustainable home/features:
    • 30,000
    • Estimate of annual savings:
    • 2,000
HOUSE DESIGN SPECIFICATIONS
    • House Size
    • 150m2
    • Roof
    • Metal (Colorbond)
    • Wall Materials
    • Lightweight construction (timber frame)
    • Window and Door Types
    • Casement
      Double glazing
    • Universal design accessability
    • Multi-generational
    • Number of bedrooms
    • 3
    • Number of bathrooms
    • 2
GARDEN AND WASTE REDUCTION
    • Garden / Outdoors
    • Composting
      Edible garden
      Orchard
      Organic
      Water wise plants
    • Waste Reduction Practices:
    • Compost all food scraps
HEALTHY HOME FEATURES
    • Healthy home features
    • Automated ventilation system
      Chemical free cleaning products used
      Cross flow ventilation
      Heat recovery ventilation (HRV)
      Natural fibre furnishings
