Tim & Anne-Marie’s Strawbale House 2024

House Notes – Tim & Anne-Marie’s Strawbale House

Our plan was to build a home at the Witchcliffe eco village that would be warm in winter, cool in summer and well-connected to the community garden at our front doorstep. We had always wanted to build with our friend Moss Johnson and his company, Wandoo Design & Construct, as we like their traditional style, easy-to-live-in houses.

In some ways the quest was to arrive at a house that complied with the high sustainability requirements of the eco village design guidelines while keeping connection to the outside world – we did not want to live in a house that doesn’t breathe or is isolated from the elements. We settled on a two-bedroom cottage (in part derived from the 100-year-old Group Settlement houses that still dot the farming landscape of the region) with bathroom, toilet and laundry to it’s south and accessed via a verandah which extends to connect to storerooms, a studio (or third bedroom) and the carport. This way the main southern door of the cottage is protected from the prevailing (and they certainly can prevail!) southwest (winter) and southeast (summer) winds. The verandah also wraps around the east and north of the cottage providing sheltered space, with a solar pergola to the north to allow winter solar access.

For materials, we went with a burnished concrete floor and zincalume roof (universal here in the village) and timber frame construction with straw bale infill, lime rendered both inside and out. Locally-sourced Australian hardwood weatherboards (wet areas, storerooms, etc) recycled jarrah joinery and pine interior cladding make for a restricted palette of fairly natural, local materials. In contrast, the HWS is a heat pump, the cooking is by induction and the solar panels/inverter talks to the microgrid via the internet.
The result is a home that feels like a warm hug but is still easy to breeze in and out of – a tribute to Moss and his team, and to our input from the experience of having lived in Witchcliffe before. We are happy to welcome you to have a look and ask any questions you may have.




This home is opening in partnership with our sponsor, Witchcliffe Eco Village. You can find out more about booking this tour here.

Come and explore Sustainable House Day in Australia’s Most Sustainable Residential Community:
  • Engage with sustainability experts
  • Join our Open House Tour to explore 6 highly sustainable solar passive homes
  • Attend Ecovillage presentations
  • Learn more about 100% renewable energy microgrids
  • Take part in community garden tours and take a look at EVs
  • 100% renewable 75 kW EV charging available on site
Don’t Miss Out!
Register your interest below to receive updates on the program, open house schedules, and an exclusive early-access sign-up for our OPEN HOUSES TOUR.
– Sustainable House Day
– ecovillage.net.au



Sustainability Features

Years Open
2024
ENERGY AND WATER EFFICIENT FEATURES
    • Energy efficiency:
    • Draught proofing
      Efficient lighting
      Efficient appliances
      Energy monitoring
      Smart home features
    • Passive heating cooling:
    • Cross ventilation

    • Passive heating cooling:
    • Winter sun on concrete floor
    • Active heating cooling:
    • Wood fire
    • Water heating:
    • Hot water heat pump
    • Water harvesting and saving features:
    • Rainwater storage - Above ground
      Stormwater management
      Low flow shower heads
      Low flow taps
      Drip irrigation
    • Average water consumption per day:
    • 50 to 100 L
    • Above ground rainwater storage Type:
    • Zincalume tanks
    • Above ground rainwater storage Size
    • 50,000 L
    • Energy Efficient Lighting
    • LED lights throughout
      Natural daylight
    • Window Protection:
    • Deciduous tree/vegetation
      Drapes/curtains
      Eaves
      Louvres
      Solar pergola
SUSTAINABLE & RECYCLED MATERIALS
    • Sustainable materials:
    • Recycled and fallen-tree jarrah roof timber Plantation hardwood cladding
    • Recycled and reused materials:
    • Basins/sinks
      Cladding
      Doors
      Paving
      Timber
INSULATION SPECIFICATIONS
    • Insulation Type:
    • Under-roof
      Ceiling
      Internal walls
      External walls
    • Ceiling Type:
    • Rock wool
    • Ceiling Rating:
    • 4
    • Under Roof Insulation Type:
    • Reflective foil and rock wool
    • Under Roof Insulation Rating:
    • 1.6
    • Internal Walls Insulation Type:
    • Rock wool
    • Internal Walls Insulation Rating:
    • 2.5
    • External Walls Rating:
    • 3.5
    • External Walls Type:
    • Straw (stawbale walls)
RENEWABLE ENERGY SPECIFICATIONS
    • All-Electric Home?
    • Yes
    • Renewable energy used:
    • Energy storage/battery
      Solar PV grid connect
    • Size of PV system:
    • 5 kW
    • Average Daily Energy Consumption:
    • 3.2 kWh/day
COSTS AND COST SAVINGS
    • Total cost of home when constructed:
    • $550,000
    • Cost estimate of sustainable home/features:
    • $480,000
HOUSE DESIGN SPECIFICATIONS
    • House Size
    • 150 m2
    • BAL Rating
    • BAL – Low: There is insufficient risk to warrant specific construction requirements
    • Roof
    • Metal (Zincalume)
    • Wall Materials
    • Strawbale
      Timber
    • Window and Door Types
    • Low-e, films
    • Universal Design Features
    • 80cm minimum door opening width
      Lever handles for doors (no knobs)
      Minimum 110cm wide hallways
      No stairs/steps
    • Number of bedrooms
    • 3
    • Number of bathrooms
    • 1
GARDEN AND WASTE REDUCTION
    • Garden / Outdoors
    • Community vegetable garden
      Composting
      Drip irrigation
      Edible garden
      Frog friendly
      Local indigenous plants
      Orchard
      Organic
      Permaculture
      Native plants
      Natural swimming pool
      Swales
      Water wise plants
    • Waste Reduction Practices:
    • Book exchange/library
      Compost all food scraps
      Make jams/conserves
      Pickle and preserve food
      Recycle
      Repair
      Recycle coffee grounds from nearby cafe's
      Take own containers to the supermarket and for take away food
      Tool exchange/library
      Toy exchange/library
      Swap with friends and neighbours
      Waste free/reduced construction site
HEALTHY HOME FEATURES
    • Healthy home features
    • Carpet free - tiles/concrete/timber flooring throughout
      Chemical free cleaning products used
      Cross flow ventilation
      Lime render/wash
      Low VOC paints/sealer/varnish
      Natural fibre furnishings
      Natural light and ventilation
      Natural oil sealer/finishes
Location
Witchclife WA 6286
    • Housing Type:
    • Standalone House
    • Project Type:
    • New Build
    • Builder
    • Wandoo Design & Construction
    • Designer
    • Moss Johnson, Anne-Marie Hoyne & Tim Dwyer
